Features and benefits:
| Dual Fuel Igniter ZAZL2… | |
|---|---|
| Outer tube diameter | 90 mm |
| Flame length (depending on nozzle size and heat release) |
max. 2200 mm |
| Outer tube length | 360 – 5000 mm |
| Oil inlet | Rp 3/8, top or bottom |
| Oil pressure | max. 5 barg |
| Atomising air port | Rp 1/4, top or bottom |
| Atomising air | max. 5 barg |
| Gas port | Rp 1, top or bottom |
| Gas inlet pressure | 150 mbarg |
| Air port | Rp 2, rotatable 4 x 90° |
| Air pressure | ≥ 20 mbarg, depending on tube length |
| Features | with integrated ignition module and ionisation flame monitor – for intermittent operation (oil) – for continuous operation (gas) |
| Power head | |
| Ignition | 2 x 7.5 kV, ignition electrode against ignition electrode |
| Ambient temperature | – 30 °C to + 60 °C |
| Protection rating | IP 54 or IP 65 |
| Dual Fuel Igniter ZAZL3… | |
|---|---|
| Outer tube diameter | 135 mm |
| Flame length (depending on nozzle size and heat release) |
max. 2500 mm |
| Outer tube length | 360 – 5000 mm |
| Oil inlet | Rp 3/8, top or bottom |
| Oil pressure | max. 5 barg |
| Atomising air port | Rp 1/4, top or bottom |
| Atomising air | max. 5 barg |
| Gas port | Rp 1, top or bottom |
| Gas inlet pressure | 150 mbarg |
| Air port | DN 80 / PN 6, rotatable 4 x 90° |
| Air pressure | ≥ 20 mbarg, depending on tube length |
| Features | with integrated ignition module and ionisation flame monitor – for intermittent operation (oil) – for continuous operation (gas) |
| Power head | |
| Ignition | 2 x 7.5 kV, ignition electrode against ignition electrode |
| Ambient temperature | – 30 °C to + 60 °C |
| Protection rating | IP 54 or IP 65 |
